125x160mm Self-Centering Vice with Fixed Jaws

$945.00 incl. GST

The TFG 125x160mm Self-Centering Vice is a robust workholding powerhouse engineered for heavy-duty CNC milling where precision centering and high clamping force are critical. Designed for seamless integration with System 96 (Ø20mm studs), this vice is built from premium tool steel and features a wide 125mm jaw and a generous 0–140mm clamping range. What sets this model apart is the combination of its high 100Nm torque capacity and fixed-jaw stability, providing superior rigidity compared to modular alternatives. With a centering accuracy of ±0.02mm, it is ideal for multi-axis machining of medium-to-large blocks and raw billets, ensuring your workpiece remains perfectly centered under the most aggressive cutting conditions.

SKU: TFG-VICE-125x160-FJ Categories: ,

Additional information

Weight 8.7 kg
Dimensions 16 × 12.5 × 8.87 cm
Material

Grid System

Clamping Stud Size

Ø20/96

Clamping Range

Clamping Force

20KN

Torque

100Nm

Centering Accuracy

±0.02mm

Jaw Width
